Article number: 14 118 04 99

Radiator screw connection

Discontinued
According to DIN 3842 for compact radiators. Straight form, lockable/adjustable.
Remember Compare Redirect Datasheet
Find contact person on site
Scope of supply Technical data Related items BIM/CAD

Scope of delivery

  • Radiator screw connection
    • Union nut, annealed

Delivery data

  • Weight: 0,33 kg/Piece
  • Packing unit: 5

Technical data

  • Max. Operating pressure: 10 bar
  • Max. operating temperature: 90 °C
  • Connection: DN 20 G 3/4 IG
  • Outlet: DN 20 R 3/4 AG with ex worked thread
  • Material: Brass
  • Surface: Matt nickel
Hint
  • Discontinued article, as long as stocks last
