E² – the digital faucets generation from SCHELL

With its factory-fitted Bluetooth® module, the E² faucets generation offers lightning-fast parameter adjustment plus logging via the SCHELL app. From wash basins to urinals, the new ToF sensor technology enables accurate operation with no accidental triggering. Discover E².

E² – simply connected | The new generation of faucets from SCHELL

Get to know the digital faucets generation

Innovative technology, intuitive app,
appealing design – that’s E²

The E² generation of wash basin taps and urinal fittings combines a wide range of product features, including Bluetooth® inside as standard, a precise sensor with time-of-flight technology and direct, toolless communication via an app.

Find out more about the new features.

  • E² benefits

    All wash basin faucets in the E² generation come equipped with the same built-in technology and are compatible with the new SCHELL app. Discover the most important product features of the new fittings generation:

    Bluetooth® inside
    Accurate operation
    User-friendly app
    Stagnation flushes
    Saving water
    Hot water limiting
    Appealing design

  • Bluetooth® inside

    All fittings in the new generation come equipped with Bluetooth® as standard, so that they can be set up and managed using the new super-efficient SCHELL app.

    • Bluetooth inside: direct connection between fitting and app without other accessories
    • Lightning-fast, intuitive commissioning, parameterisation and logging via app for one or more E² fittings
    • No need for complicated, time-consuming short-range reflex programming

  • Accurate operation

    With its new time-of-flight technology, the fitting’s sensor system is highly accurate, which makes accidental triggering – by reflections or incident light, for example – a thing of the past.

    • Innovative ToF (time-of-flight) technology
    • No accidental triggering – e.g. by light reflected from stainless steel bowls or hi-vis vests
    • Compact, reflection-proof sensor module with IP67 rating
    • LED in sensor window indicates states such as low battery level and cleaning stop

  • User-friendly app

    The intuitive app makes it easy to set local fitting parameters via Bluetooth®, read off fitting states, and gain quick and reliable access to fitting data.

    • Instant fitting start-up, including commissioning report via the app
    • Easy log record access and exporting
    • Group manager for configuring and managing local groups of fittings more effectively
    • Create buildings and rooms to ensure straightforward data access and management
    • Stagnation flushes, cleaning stop, continuous flow and thermal disinfection configurable and triggerable via app

  • Stagnation flushes

    Alongside a new mode – ‘Flush while accounting for usage’ – a date series can also be entered into the app to ensure the precise configuration of stagnation flushes.

    • New setting options for better plannability, accounting for usage levels and reduced water consumption
    • Thanks to a real-time clock, scheduled stagnation flushes are possible using a convenient date series, e.g. at times of low usage
    • Automatic flushing while accounting for usage: demand-based flushing if water consumption drops below a specified level within a certain period of time

  • Saving water

    Alongside the option for custom settings with expert mode, three preconfigured operating modes are also available, to make parameter setting on E2 fittings even faster: Save water, Save electricity and Comfort.

    • Save water mode: to cut consumption, the flow of water stops quickly when the user moves out of sensor range
    • Save electricity mode: power-saving sensor frequency for a long battery life
    • Comfort mode: quick start and long flow of water for user-friendly operation
    • Expert mode: customised configuration of options to match local circumstances and customer needs (e.g. detection range, flow/follow-up time, etc.)

  • Hot water limiting or thermostat

    All HD-M faucets in the new series are equipped with mechanical hot water limiting, allowing individual adjustment of the maximum flow of hot water through the faucet. The XERIS E-T features a ThermoProtect thermostat with reliable anti-scalding protection.

    • All HD-M faucets have easy-to-adjust, mechanical hot water limiting without a thermostat.
    • XERIS E-T plus ThermoProtect thermostat with reliable anti-scalding protection and instant water stop if the cold water line fails

  • Attractive design

    The new fittings generation makes a splash with its robust, easy-to-clean all-metal housing and timeless design.

    • Timeless design
    • Vandal-resistant, easy-to-clean, durable all-metal housing
    • Anti-theft recessed flow regulator

Overview of app functions

Simply connected with the new SCHELL app

Local direct connection
Operating modes
Expert mode
Stagnation flushes
Smart demand-based flushing
Thermal disinfection
Building management
Logging
Statistics
Cleaning stop
Messages/status indicator
Continuous flow

  • Direct connection between fitting and app

    Functional details:
    Thanks to Bluetooth® inside as standard, a local, direct connection between fitting and app is possible without other accessories. This means that any E² fitting within Bluetooth® range can be adjusted quickly and easily with the app.

  • Choice of three preconfigured modes at the wash basin

    Functional details:
    For lightning-fast parameter setting on SCHELL E² wash basin faucets, simply select one of the three preconfigured modes in the E² app: the ‘Save water’ mode ensures a quick stop to the flow of water, the ‘Save energy’ mode extends faucet battery life and the ‘Comfort’ mode keeps the water flowing until handwashing is complete.

  • Custom parameter setting at the wash basin

    Functional details:
    Expert mode is perfect for making custom settings to SCHELL E² wash basin faucets using the E² app. In this mode, the sensor range, the sensor response time, the follow-up time and other faucet parameters can all be adjusted to perfectly match local circumstances and customer needs.

  • Stagnation flushes

    Functional details:
    Setting up stagnation flushes with the E² app couldn’t be easier. Apart from interval-based flushes, the built-in real-time clock also allows the creation of date series. All that needs to be entered is the flow time, start time and day, for example 3 min 30 s, flush at 11 p.m. Saturdays and Sundays.

  • App-based thermal disinfection on the wash basin

    Functional details:
    Thermal disinfections can be triggered on the wash basin from a safe distance with the E² app . Only the flow time needs to be set up beforehand and then the process can be started with the ‘Play’ button. The app prompts for confirmation and the flow of water then starts.

  • Building and room overview in the app

    Functional details:
    The building management functions in the E² app can be used to create buildings and rooms to ensure effortless access to operating data. Battery levels and any action required can be viewed at a glance. The individual room views can be used to access data and stagnation flushes across multiple rooms can also be triggered if needed, for example.

  • Proof of compliance with legal requirements

    Functional details:
    E² simplifies the record-keeping process needed for legal compliance, with convenient logging of scheduled events and water consumption (calculated). These logs can be easily accessed and exported for use elsewhere.

  • Access triggering data, battery charge, etc.

    Functional details:
    Statistics for SCHELL E² fittings can be conveniently accessed with the E² app. Status messages about battery charge, water consumption (calculated), triggering and more are presented in detail in a clearly structured layout. Sharing statistics with others is also straightforward with the ‘Share data’ button.

  • Trigger cleaning stop via app

    Functional details:
    The cleaning stop can be set easily using the E² app. First, the flow time needs to be adjusted and then the cleaning stop can be started with the ‘Play’ button. This can also be triggered on the fitting without a smartphone via short-range reflex. The sensor LED flashes while the cleaning stop is active.

  • Battery charge and actions required

    Functional details:
    Information about the E² fittings is easily accessible from within the app and clearly presented. Messages are used to flag up any actions required The status indicator provides information about battery charge, usage, commissioning and more.

  • Trigger continuous flow without confirmation instead of manual flush

    Functional details:
    Manual flushes via continuous flow can also be triggered for wash basin faucets using the E² app. After selecting the flow time, the process can be started with the ‘Play’ button. The app prompts for confirmation and the flow of water then starts.

Intelligent SCHELLTRONIC E² functions

App-driven efficiency at the urinal

Der SCHELLTRONIC E² offers a special set of functions that ensure efficient, economical and reliable operations even if usage levels fluctuate – all of which can be easily activated via the app.

individuelle-einstellungen

Individual settings

Sensor range and flush duration can be easily adjusted with the app. The app can also be used to activate a pre-flush to improve hygiene.

hybridspuelung

Hybrid flush

With the hybrid flush, the fitting does not flush with water after each use but only at fixed intervals. This setting can be used for especially resource-friendly operations.

stadionbetrieb

Stadium mode

In stadium mode, the urinal control will switch automatically to a reduced flush volume as user frequency increases. This keeps operations efficient and cost-effective during peak times.

geruchsverschluss-spuelung

Odour trap flush

The odour trap flush refills the odour trap with water at predefined intervals and can be individually adjusted to ensure reliable odour protection during normal operations.

Four families – one generation

Discover the families in the E² faucets generation

The new E² faucets generation includes wash basin faucets from three of our popular SCHELL faucet families as well as the SCHELLTRONIC E² series of exposed urinal flush valves. This broad product portfolio ensures that various kinds of installation scenarios and a wide range of requirements can be catered to.

schell_e2_xeris-e2
schell_e2_xeris-e2_hover
XERIS E² – prize-winning look-and-feel

With its impressive elegance and formal contours, the XERIS family combines a feature-packed technical interior with flawless hygiene and an appealing design.

Go to XERIS family

Schell_e2_celis-e
schell_e2_celis-e2_hover
CELIS E² – first-class hygiene

The harmonious proportions of this timeless design are characteristic of the CELIS family. Thanks to the low body height, CELIS models are also ideal for use even where space is limited.

Go to CELIS family

schell_e2_puris-e2
schell_e2_puris-e2_hover
PURIS E² – robust and durable

The PURIS family offers robust reliability paired with a clean and aesthetically appealing design. The vandal-resistant, all-metal body blends seamlessly with any facility decor.

Go to PURIS family

SCHELLTONIC_hover
Schelltronic-hover-2
Efficient operations with SCHELLTRONIC E²

Featuring a modern, high-quality and vandal-resistant design, the SCHELLTRONIC E² family offers water-efficient functions like ‘stadium mode’.

Go to the SCHELLTRONIC family

All E² products at a glance

App-solutely perfect: how E² makes your work easier

Building operator

E² makes it easy for building operators to keep tabs on their buildings and fittings. The detailed data analysis offered by the SCHELL app highlights any actions required, and makes job planning quick and efficient. With options for custom settings – such as stadium mode on urinals – and individual stagnation flushes, the water-saving fittings simplify efforts to lower operating costs.

Benefits:

  • Better overview of buildings and fittings
  • Proactive planning of to-dos
  • Cut operating costs with economical (settings for) fittings
Get in touch

Planner

The many models available for the digital SCHELL E² fittings generation offer matching solutions for a huge variety of installation scenarios in both new developments and renovation projects. The fittings help to maintain drinking water hygiene thanks to their comprehensive options for setting up stagnation flushes and therefore simplify planning work. The economical fittings improve cost-effectiveness and sustainability for projects – even at the draft stage.

Benefits:

  • Comprehensive portfolio of fittings for any installation scenario
  • Help with maintaining drinking water hygiene
  • Economical fittings for future-oriented, budget-focused projects
Get in touch

Tradesperson

With the digital E² fittings generation, intuitive and lightning-fast app-based fitting setup becomes possible thanks to Bluetooth® being integrated as standard. This avoids complicated and time-consuming adjustments via short-range reflex and the need for other accessories. Predefined profiles for the wash basin faucets make parameter setting especially straightforward. The group manager can be used for the efficient setup of local fitting groups.

Benefits:

  • Lightning-fast fitting setup with no short-range reflex
  • Easy parameter setting with predefined profiles for the wash basin faucets and an intuitive app design
  • Group manager for local fitting groups
Get in touch
SCHE_Webbild_Broschueren-Mock-Up_E2_EN_1140x746px-b

With an eye for detail:
the E² brochure

Read our comprehensive brochure to discover all of the benefits of the digital SCHELL E² fittings generation.

Download brochure

FAQ for the SCHELL E² generation of digital fittings

Easy commissioning.

All you need is the new E2 app. The intuitive menus in the app guide you through the process of making any necessary settings.
Visit our blog to find out more.

The E2 app can be used to copy settings from one fitting to another fitting of the same model in just a few steps.
A group manager is also available for local fitting groups. Visit our blog to find out more.

The ‘Save water’ mode for the E2 fittings ensures a quick stop to the flow of water, the ‘Save energy’ mode
extends battery life and the ‘Comfort’ mode starts the flow of water quickly and keeps it running for longer. Visit our blog
to find out more.

In the E2 app, look for the prominently placed ‘Share data’ button. Use this to choose where data should be sent with an email or
as a WhatsApp text. Alternatively, the data can also be stored directly in the app. Visit our
blog to find out more.

Simple facility management

In the E2 app, you can either use the building view to access analyses of consumption (calculated) and flushes
or you can access the individual statistics that are stored for each fitting. Visit our blog to find out more.

The ‘Stagnation flushes’ menu option is available in the app for every E2 fitting. This can be used to set up flushes as date series, for example. Settings profiles that include stagnation flushes can be copied locally to fittings of the same model. Visit our blog to find out more.

In the E2 app, look for the prominently placed ‘Share data’ button. Use this to choose where data should be sent with an email or
as a WhatsApp text. Alternatively, the data can also be stored directly in the app. Visit our
blog to find out more.

Modern sensor technology

The time-of-flight (ToF) technology measures the time taken by an outbound pulse of light reflected back to the sensor from an object –
like the user’s hands. The sensor then uses this period of time to calculate the distance in real time
and can start or stop the flow of water once the range is correctly configured. Visit our blog to find out more.

Switch the E2 app to expert mode: you can then adjust the sensor range and incrementally adjust the sampling rate. Visit
our blog to find out more.
