Article number: 01 296 06 99

Electronic wash basin tap XERIS E

Discontinued SSC SWS

HD-M small - high-pressure mixed water

Infrared sensor-controlled. Battery operation. Suitable for networking with the SCHELL SWS water management system. Configurable via SCHELL Single Control SSC.

Remember Compare Redirect Datasheet

Find contact person on site

Scope of delivery

Infrared sensor single-hole tap

Temperature controller
Infrared sensor electronics, programmable
6 V axial solenoid valve with pre-filter
Aerator
Connection cable, 250 mm, with 3-pin plug connector, protection class IP65

6 V battery compartment, protection class IP65
4x AA alkaline battery 1.5 V
2 flexible Clean-Fix S connection hoses, G 3/8 IG x 400 mm, with integrated backflow preventer (EN 1717: EB-type) and pre-filter
Fastening material for wash basin installation

Delivery data

Weight: 1,84 kg/Piece
Packing unit: 1

Technical data

Setting options via SWS SSC

Sensor range (short/medium/long)
Programming via short range reflex (off/on)
Max. flow time (1-360 s)
Follow-up time (0.6-60 s)
Stagnation flush (off/5-600 s, every 1-240 h after last flush/every 1-240 h)
Continuous flush for thermal disinfection, with anti-scalding protection (off/15-600 s)
Duration of flow (off/15-600 s)
Energy saving mode (off/1-254 h after last flush)
Cleaning stop (off/60-360 s)

Setting options via short range reflex

Sensor range (short/medium/long)
Stagnation flush (off/30 s, every 24 h after last flush/every 24 h)
Continuous flush for thermal disinfection, with anti-scalding protection (off/300 s/120 s)
Cleaning stop (off/60 s)

Flow: max. 5 l/min pressure independent
Flow pressure: 1.0 - 5.0 bar
Max. Resting pressure: 8 bar
Max. operating temperature: 70 °C (80 °C for thermal disinfection)
Material: Housing Brass; Parts in contact with water Plastic
Surface: Chrome
Certificates: PA-IX 29072/IO, Belgaqua, WRAS applied
Noise class: I
Flow class: O
